可供版本
| |
Code | l x w x h
(mm) | Max
(kg) | d
(g) |
(g)* |
2R (g)* | d HR
(g)* | Notes |
| WI33-6-PRO | 330x330x90 | 6 | 1 | 2 | 1-2 | 0,2 | |
| WI33-15-PRO | 330x330x90 | 15 | 2 | 5 | 2-5 | 0,5 | |
| WI33-30-PRO | 330x330x90 | 30 | 5 | 10 | 5-10 | 1 | |
| WI44-30-PRO | 400x400x115 | 30 | 5 | 10 | 5-10 | 1 | |
| WI44-60-PRO | 400x400x115 | 60 | 10 | 20 | 10-20 | 2 | |
| WI44-150-PRO | 400x400x115 | 150 | 20 | 50 | 20-50 | 5 | |
| WI45-30-PRO | 400x500x115 | 30 | 5 | 10 | 5-10 | 1 | |
| WI45-60-PRO | 400x500x115 | 60 | 10 | 20 | 10-20 | 2 | |
| WI45-150-PRO | 400x500x115 | 150 | 20 | 50 | 20-50 | 5 | |
| WI66-60-PRO | 600x600x137 | 60 | 10 | 20 | 10-20 | 2 | |
| WI66-150-PRO | 600x600x137 | 150 | 20 | 50 | 20-50 | 5 | |
| WI66-300-PRO | 600x600x137 | 300 | 50 | 100 | 50-100 | 10 | |
| WI33-6-PRO-UK | 330x330x90 | 6 | 1 | 2 | 1-2 | 0,2 | UK PLUG |
| WI33-15-PRO-UK | 330x330x90 | 15 | 2 | 5 | 2-5 | 0,5 | UK PLUG |
| WI33-30-PRO-UK | 330x330x90 | 30 | 5 | 10 | 5-10 | 1 | UK PLUG |
| WI44-30-PRO-UK | 400x400x115 | 30 | 5 | 10 | 5-10 | 1 | UK PLUG |
| WI44-60-PRO-UK | 400x400x115 | 60 | 10 | 20 | 10-20 | 2 | UK PLUG |
| WI44-150-PRO-UK | 400x400x115 | 150 | 20 | 50 | 20-50 | 5 | UK PLUG |
| WI45-30-PRO-UK | 400x500x115 | 30 | 5 | 10 | 5-10 | 1 | UK PLUG |
| WI45-60-PRO-UK | 400x500x115 | 60 | 10 | 20 | 10-20 | 2 | UK PLUG |
| WI45-150-PRO-UK | 400x500x115 | 150 | 20 | 50 | 20-50 | 5 | UK PLUG |
| WI66-60-PRO-UK | 600x600x137 | 60 | 10 | 20 | 10-20 | 2 | UK PLUG |
| WI66-150-PRO-UK | 600x600x137 | 150 | 20 | 50 | 20-50 | 5 | UK PLUG |
| WI66-300-PRO-UK | 600x600x137 | 300 | 50 | 100 | 50-100 | 10 | UK PLUG |
(*) Divisions obtainable only with the relative options
适用于贸易审批 （仅在订单时有效）
高分辨率（d HR）（仅在订购时提供）
| | 型号 | 说明 |
| CT3 | ISO 17025 (ACCREDIA/DAKKS)：标定证书，为量程不超过5kg的工业秤、吊秤使用。 |
| CT4 | ISO 17025 (ACCREDIA/DAKKS)：标定证书，为量程5 - 60kg的工业秤、吊秤使用。 |
| CT5 | ISO 17025 (ACCREDIA/DAKKS)：标定证书，为量程不超过60 - 300kg的工业秤、吊秤使用。 |
立柱和支撑支架
| | 型号 | 说明 |
| TCBI350-3 | Stainless Steel column, length 350mm, equipped with a cable reel, for installation integral with T, TE, PB, PBI series platforms. Indicator support bracket excluded, (to be combined with DFWXCL or 3590CL). NOTE: -2 column models do not include the indicator holder bracket. |
| TCBI500-2 | Stainless Steel column, length 500mm, for installation integral with T, TE, PB, PBI series platforms. Indicator support bracket excluded, (to be combined with DFWXCL or 3590CL). |
| TCBI700-2 | Stainless Steel column, length 700mm, for installation integral with T, TE, PB, PBI series platforms. Indicator support bracket excluded (to be combined with DFWXCL or 3590CL). |
连接电缆
Optional power supply cords
| | 型号 | 说明 |
| PWCORDCH | 电源线配SEV1011插头（CH插头）。 |
| PWCORDUS | 配备美国B型电源线版本 （日本、北美和中美洲）。 |
| PWCORDAUS | 配备AU电源线的版本。 |
| | 型号 | 说明 |
| FO-ALMEM | Alibi Memory board, assembly included. |
打印机/标签机
| | 型号 | 说明 |
| PR80-3 | (S1) Thermal printer with print cutter. Paper roll not included. |
| LP542TE | (S1) Direct termal labeller. 标签可剥离式热敏标签打印机，配有连接称重显示器的1.5m长RS232电缆，外接100/240Vac电源适配器。 |
Roller unit
??:???ATEX???
| ?????/????? |
| ???? |
?? |
?????? |
?????? |
| TTE-RP |
X |
X |
| TQE-RP |
WI44-30-PRO |
X |
- |
| WI44-60-PRO |
X |
X |
| X |
X |
| TXE-RP |
WI66-60-PRO |
X |
X |
| X |
X |
| WI66-300-PRO |
X |
X |
